Disc Harrow

Disc Harrow

See the differeance at First Tillage

It is widely used for tillage, especially for sowing preparation and stubble
cultivation. With its combined design, it reduces production costs. The required quality
of land cultivation can be achieved if the work is done at a speed of up to 15 km / h
under proper soil conditions. The high performance brings low costs and low fuel
consumption. 510mm toothed discs are attached to the frame with rubber springs. Withthis structure, adding soil and plant parts to the soil by crushing, a great effect isachieved. It is an ideal machine for minimal tillage that has become important in the last
few years. With this machine, it is possible to mix plant parts in the best way by
crushing, which is more useful for the plant, leading to the restoration of the biological
balance of the soil.

Specifications

Model Disc Nr Req Tractor HP Disc Dia (cm) Weight (Kg) Working Width (cm) Transport Width (cm)
RMDH-16 16 70/130 51/56/61 850 200 220
RMDH-18 18 80/120 51/56/61 960 225 245
RMDH-20 20 80/120 51/56/61 1050 250 270
RMDH-22 22 100/140 51/56/61 1150 275 295
RMDH-24 24 100/140 51/56/61 1300 300 320
RMDH-28 28 120/160 51/56/61 1660 350 370
