Cotton Baler
Specifications

Unlock the power of your cotton harvest with the Rime 1600 Cotton Baler!
Get ready to experience maximum efficiency and minimum losses like never before. With its variable chamber, this innovative equipment processes harvested cotton quickly and effectively, forming heavier and cleaner cotton rolls. Reduce contamination and improve logistics process with a baler that takes your business to the next level. Maximize your earnings today with the Rime 1600 Cotton Baler!
Logistic efficiency
Our new model has a variable compaction chamber that increases the density of raw cotton by 10 times, so you can optimize the load capacity of trucks. From the fields into the warehouses or from warehoused to gins, large amounts of cotton are transported compactly in bales. It also allows to load as many cotton bales as possible (1 pc cotton bale = 160 x 120 cm - 800kg) onto trucks as permitted by traffic rules. Max payload of standart trailers can be used efficiently. It saves 3 times less then traditional transport ways.
Fast and easy handling
It's the most efficient way to bale 800 kg of cotton fast. With intuitive design and power-efficient features, it takes just a few minutes to get each wrap cycle done. You'll be able to save valuable time and get more cotton wrap rolled with less effort. Get your hands on the Rime Cotton Baler to maximize your productivity today!
Safe and efficient storage
Get your cotton ready for storage with the Rime Cotton Baler! Since cotton bales will not absorb water inside, they can be kept outside. Our revolutionary design offers six months of protection against impurities and rain, while non-PVC wrapping film keeps it safe and secure. Saves 2/3 of space in closed warehouses compared to traditional methods. Enjoy peace of mind knowing that your cotton is stored securely, with no contaminants or damage. Get Rime Cotton Baler for the ultimate in cotton storage protection!
Cotton Classification
Cotton that is kept for ginning in warehouses or outdoors can be mixed with cotton of different types and humidity from many different sources/suppliers. Different cottons at different humidity levels may interact with each other and cause them to lose their quality.
With the Rime Cotton Baler machine, cottons from different suppliers can be baled, sorted and labeled according to their quality. In this way, quality and moisture interactions are prevented. This method ensures that the sorted moist products are primarily ginned without delay, so no more quality losses of the sorted moist products. This makes it possible to gin dry cotton at a later date without having any storage or quality problems. Thus, the ginning factory uses its capacity to the maximum and allows it to work even after the harvest season.
Low Energy consumption
Cb 1600 Cotton Baling Machine is equipped with PLC control system with Intelligent algorithm. The Rime Cotton Baler is powered by electricity and uses 2 Kw/bale energy. It works with electricity which is a green energy product.
Mobility
It can be carried anywhere with a 60 hp tractor and get ready to work in a minute.












| TECHNICAL SPECIFICATIONS | COTTON BALERS |
|---|---|
|
TECHNICAL SPECIFICATIONS
DESCRIPTION
|
COTTON BALERS
RIME COTTON BALER
|
|
TECHNICAL SPECIFICATIONS
MODEL NAME
|
COTTON BALERS
RMCB-1600
|
|
TECHNICAL SPECIFICATIONS
ENERGY
|
COTTON BALERS
|
|
TECHNICAL SPECIFICATIONS
ENERGY SOURCE
|
COTTON BALERS
380 V (3 Phase)
|
|
TECHNICAL SPECIFICATIONS
TOTAL POWER REQ.
|
COTTON BALERS
30 Kw
|
|
TECHNICAL SPECIFICATIONS
POWER CONSUMPTION
|
COTTON BALERS
3 kWh/ton
|
|
TECHNICAL SPECIFICATIONS
MIN GENERATOR POWER REQ.
|
COTTON BALERS
50 kW
|
|
TECHNICAL SPECIFICATIONS
BALE CAVITY ENGINE POWER
|
COTTON BALERS
22 kW
|
|
TECHNICAL SPECIFICATIONS
CAPACITY
|
COTTON BALERS
|
|
TECHNICAL SPECIFICATIONS
BALE CAPACITY
|
COTTON BALERS
12 bale/hour
|
|
TECHNICAL SPECIFICATIONS
DAILY CAPACITY (10 HOURS)
|
COTTON BALERS
120 bale/day
|
|
TECHNICAL SPECIFICATIONS
BUNKER CAPACITY
|
COTTON BALERS
8 m3
|
|
TECHNICAL SPECIFICATIONS
BUNKER TYPE
|
COTTON BALERS
Top Side Loading
|
|
TECHNICAL SPECIFICATIONS
CONTROL SYSTEMS
|
COTTON BALERS
|
|
TECHNICAL SPECIFICATIONS
ELECTRONIC CONTROL SYSTEM
|
COTTON BALERS
PLC
|
|
TECHNICAL SPECIFICATIONS
TOUCH SCREEN
|
COTTON BALERS
Standard
|
| TECHNICAL SPECIFICATIONS | COTTON BALERS |
|---|---|
|
TECHNICAL SPECIFICATIONS
BALE DIMENSIONS
|
COTTON BALERS
|
|
TECHNICAL SPECIFICATIONS
HEIGHT
|
COTTON BALERS
1200 mm
|
|
TECHNICAL SPECIFICATIONS
DIAMETER
|
COTTON BALERS
1600 mm
|
|
TECHNICAL SPECIFICATIONS
WEIGHT
|
COTTON BALERS
750-850 kg
|
|
TECHNICAL SPECIFICATIONS
NET FILM DIM.
|
COTTON BALERS
|
|
TECHNICAL SPECIFICATIONS
NET WIDTH
|
COTTON BALERS
1400 mm
|
|
TECHNICAL SPECIFICATIONS
NET LENGTH
|
COTTON BALERS
2000 mt (3 layer)
|
|
TECHNICAL SPECIFICATIONS
GENERAL INFO&DIMENSIONS
|
COTTON BALERS
|
|
TECHNICAL SPECIFICATIONS
LENGTH (TRANSPORT)
|
COTTON BALERS
7000 mm (+drawbar)
|
|
TECHNICAL SPECIFICATIONS
LENGTH (WORK)
|
COTTON BALERS
6000 mm
|
|
TECHNICAL SPECIFICATIONS
WIDTH (TRANSPORT)
|
COTTON BALERS
2600 mm
|
|
TECHNICAL SPECIFICATIONS
WIDTH (WORK)
|
COTTON BALERS
2800 mm (+ladder)
|
|
TECHNICAL SPECIFICATIONS
HEIGHT (TRANSPORT)
|
COTTON BALERS
3800 mm
|
|
TECHNICAL SPECIFICATIONS
HEIGHT (WORK)
|
COTTON BALERS
3800 mm
|
|
TECHNICAL SPECIFICATIONS
AXLE
|
COTTON BALERS
Single
|
|
TECHNICAL SPECIFICATIONS
TRACTOR CONNECTION
|
COTTON BALERS
Drawbar
|
|
TECHNICAL SPECIFICATIONS
WEIGHT
|
COTTON BALERS
7250 kg
|
|
TECHNICAL SPECIFICATIONS
AUTOMATIC LUBRICATION
|
COTTON BALERS
Optional
|
|
TECHNICAL SPECIFICATIONS
COMPACTING UNIT
|
COTTON BALERS
Endless Rubber Belt
|
